The image shown here is for illustrative purposes only.
SWITCH
Code: 30.34.10300.01
€13.00
Tax excluded
(15.86 € Tasse incluse)
Quantity
- SSL 100% secure website
- Fast shipping with national and international couriers
Description
| RATED VOLTAGE | MAX DIRECT CURRENT (A) | PEAK CURRENT 5" (A) | SEALING (IEC 529) | OPERATING TEMPERATURE (°C) | N° LIFE CYCLES |
|---|---|---|---|---|---|
| 12V | 10 A resistivi/resistive | IP53 | - 20°C ÷ + 55°C | 10.000 | |
| 24V | 5 A resistivi/resistive | IP53 | - 20°C ÷ + 55°C | 10.000 |
TERMINALS
2 BLADE TERMINALS 6.35X0.8 MM.
NR. POSITION
1 MOMENTARY POSITION
TIGHTEN TORQUE
1,50 Nm
MAX PANEL THICKNESS
4,5 mm
APPLICATIONS
