The image shown here is for illustrative purposes only.
STEERING COLUMN SWITCH
Code: 01.0773.0600.01
Doc. Code: 01-0773-0600-01
€233.50
Tax excluded
(284.87 € Tasse incluse)
Quantity
- SSL 100% secure website
- Fast shipping with national and international couriers
Description
| FUNCTION | PEAK LOAD 12V | PEAK LOAD 24V |
|---|---|---|
| FORWARD GEAR | 200mA | 100mA |
| NEUTRAL | 200mA | 100mA |
| REVERSE GEAR | 200mA | 100mA |
| SPEED 1 | 200mA | 100mA |
| SPEED 2 | 200mA | 100mA |
| SPEED 3 | 200mA | 100mA |
| AUTOMATIC GEARBOX | 200mA | 100mA |
LENGTH LEVER MM
201-300
STEERING HEIGHT MM
0-100
TYPE
SINGLE
FITTING POSITION
LH
TECHNOLOGY
FRONTALI IN ARIA
TYPE CONNECTION
DEUTSCH 12 VIE
LENGTH LEVER MM DETAIL
242
STEERING HEIGHT MM DETAIL
78
MODEL TYPE
SERIE 2000
FUNCTION - AUTOMATIC GEARBOX
Attivo
FUNCTION - SPEED 3
Attivo
FUNCTION - SPEED 2
Attivo
FUNCTION - SPEED 1
Attivo
FUNCTION - BLOCK
Attivo
FUNCTION - REVERSE GEAR
Attivo
FUNCTION - NEUTRAL
Attivo
FUNCTION - FORWARD GEAR
Attivo
APPLICATIONS
