The image shown here is for illustrative purposes only.
OIL PRESSURE SWITCH
Code: 2m02f003.01
Doc. Code: 2M02F003
€91.60
Tax excluded
(111.75 € Tasse incluse)
Quantity
- SSL 100% secure website
- Fast shipping with national and international couriers
Description
| PRESSURE (BAR) | RESISTANCE (ohm) |
|---|---|
| 0 | 0 ÷ 20 |
| 6 | 126 ÷ 144 |
| 10 | 170 ÷ 190 |
HOUSING MATERIAL
ZN-CR PLATED
THREAD
1/8 28 BSP
KEY
EXAGON 17 MM.
POWER SUPPLY VOLTAGE V
12-24V
CONNECTION
2 KNURLED NUT BUTTONS
TYPE OF BUTTON
NORMALLY CLOSED
SWITCH OPENING PRESSURE BAR
0.9 ÷ 1.2
APPLICATIONS
