The image shown here is for illustrative purposes only.
STEERING COLUMN SWITCH
Code: 01.488.500.01
Doc. Code: 01-488-500-01
€415.15
Tax excluded
(506.48 € Tasse incluse)
Quantity
- SSL 100% secure website
- Fast shipping with national and international couriers
Description
| FUNCTION | PEAK LOAD 12V | PEAK LOAD 24V |
|---|---|---|
| HORN | 3A | 1,5A |
| LOW BEAM | 15A | 7A |
| HIGH BEAM | 6A | 3A |
| FLASHING | 6A | 3A |
| DIRECTION | 6A | 3A |
| WINDSCREEN WASHER | 3A | 1,5A |
| INTERMITTENT WIPERS | 3A | 1,5A |
| WINDSCREEN WIPER 1 | 3A | 1,5A |
| WINDSCREEN WIPER 2 | 3A | 1,5A |
LENGTH LEVER MM
201-300
STEERING HEIGHT MM
0-100
TYPE
SINGLE
FITTING POSITION
RH
TECHNOLOGY
FRONTALI IN ARIA
TYPE CONNECTION
DEUTSCH 12 VIE
DEUTSCH 4 VIE
LENGTH LEVER MM DETAIL
257
STEERING HEIGHT MM DETAIL
90
MODEL TYPE
SERIE 2000
FUNCTION - HORN
Attivo
FUNCTION - LOW BEAM
Attivo
FUNCTION - HIGH BEAM
Attivo
FUNCTION - FLASHING
Attivo
FUNCTION - DIRECTION
Attivo
FUNCTION - WINDSCREEN WASHER
Attivo
FUNCTION - INTERMITTENT WIPERS
Attivo
FUNCTION - WINDSCREEN WIPER 1
Attivo
FUNCTION - WINDSCREEN WIPER 2
Attivo
APPLICATIONS
