The image shown here is for illustrative purposes only.
STEERING COLUMN SWITCH
Code: 01.218.000.01
Doc. Code: 01-218-000-01
€302.35
Tax excluded
(368.87 € Tasse incluse)
Quantity
- SSL 100% secure website
- Fast shipping with national and international couriers
Description
| FUNCTION | PEAK LOAD 12V | PEAK LOAD 24V |
|---|---|---|
| HORN | 5A | 3A |
| LOW BEAM | 6,5A | 4,5A |
| HIGH BEAM | 7A | 5A |
| FLASHING | 7A | 5A |
| DIRECTION | 7A | 5A |
| MAIN LIGHTING | 3A | 3A |
| WINDSCREEN WASHER | 5A | 3A |
| INTERMITTENT WIPERS | 1,8A | 1A |
| WINDSCREEN WIPER 1 | 8A | 5A |
| WINDSCREEN WIPER 2 | 9A | 6A |
LENGTH LEVER MM
201-300
STEERING HEIGHT MM
101-200
CONNECTION LENGTH MM
401-500
LENGTH LEVER 1 MM
201-300
STEERING HEIGHT 1 MM
101-200
CONNECTION LENGTH 1 MM
401-500
FIXING
COLUMN 32 MM
TYPE
DOPPIO
TECHNOLOGY
FRONTALI IN ARIA
LENGTH LEVER MM DETAIL
265
STEERING HEIGHT MM DETAIL
155
CONNECTION LENGTH MM DETAIL
460
LENGTH LEVER 1 MM DETAIL
235
STEERING HEIGHT 1 MM DETAIL
160
CONNECTION LENGTH 1 MM DETAIL
460
COLOUR
BLACK
MODEL TYPE
SERIE 246
FUNCTION - HORN
Attivo
FUNCTION - LOW BEAM
Attivo
FUNCTION - HIGH BEAM
Attivo
FUNCTION - FLASHING
Attivo
FUNCTION - DIRECTION
Attivo
FUNCTION - RIENTRO AUTOMATICO
Attivo
FUNCTION - WINDSCREEN WASHER
Attivo
FUNCTION - INTERMITTENT WIPERS
Attivo
FUNCTION - WINDSCREEN WIPER 1
Attivo
FUNCTION - WINDSCREEN WIPER 2
Attivo
FUNCTION - MAIN LIGHTING
Attivo
APPLICATIONS
