The image shown here is for illustrative purposes only.
BUZZER
Code: 31.025.000.01
Doc. Code: 31-025-000-01
€77.00
Tax excluded
(93.94 € Tasse incluse)
Quantity
- SSL 100% secure website
- Fast shipping with national and international couriers
Description
BUZZER ASY-TURN INDICATOR
WORKING CHARACTERISTICS
Water and dust protection: IP30 - Working and storage temperature: - 40°C / +80°C - Buzzer unit shall begin to sound in phase with the flasher unit after 28" -/+ 5% - Buzzer unit will sound
continuously with key switch on and handbrake pulled. Handbrake is predominant on flasher unit.
WORKING CHARACTERISTICS
Water and dust protection: IP30 - Working and storage temperature: - 40°C / +80°C - Buzzer unit shall begin to sound in phase with the flasher unit after 28" -/+ 5% - Buzzer unit will sound
continuously with key switch on and handbrake pulled. Handbrake is predominant on flasher unit.
RATED VOLTAGE
12V
ABSORBED CURRENT
88,2 mA - /+ 10% @ Vcc=13,5Vdc
MINIMUM SOUND PRESSURE CM.60
75 Db a 1metro/metre @ saej994
OPERATING FREQUENCY
2048 Hz - /+ 5%
APPLICATIONS
